14寸电容屏 WGJ14005A-GDA-A1

14寸电容屏 WGJ14005A-GDA-A1

  • 型号: WGJ14005A-GDA-A1
  • 产品摘要: 风扬光电专业生产14寸电容式触摸屏,型号WGJ14005A-GDA-A1
  • 产品型号(Model No.):WGJ14005A-GDA-A1

        厚度(Thickness):2.0 mm

        外形尺寸(Outline Dimensional):335mm*200mm

        可视区域(View Area): 311mm*176mm

        结构类型(Panel structure): G+G

        操作温度(Temperature range): -20℃~+70℃

        储存温度(Humidity range): -30℃~+80℃

        工作电压(Working voltage): DC5.0V

        线性精度(Linear equation): ≤2%

        透光率(Optical Characteristics) : ≥87%

        表面硬度(Surface Hardness):  ≥ 6H



        NEOSER make the Capacitive touch panel WGJ14005A-GDA-A114寸电容屏 WGJ14005A-GDA-A1(图1), from the size 2.8inch to 85inch, Pls connect with display@neoser.com



    14寸电容屏 WGJ14005A-GDA-A1(图2)

    •     触摸点数(Touch point):10
